What is the function of induction melting furnace yoke?

Time:2021-03-24   Nums:1315

The profiling yoke is built in the induction melting furnace body. The yoke shielding can reduce the magnetic flux leakage, prevent the furnace body from heating and improve the efficiency. At the same time, the magnetic yoke can support and fix the induction coil, so that the furnace body can achieve high strength and low noise. The yoke is a crescent shaped yoke made of cold-rolled silicon steel sheet and stainless steel splint. The joint surface of the iron core and the coil is a circular arc surface, and the pressing place is a surface rather than a line in the past. This structure has good pressing effect and less magnetic leakage. After the silicon steel sheet is stacked, it is tightened with special splint instead of special through screw. This structure can make full use of the magnetic conductive area of silicon steel sheet and reduce the possibility of local heating of induction furnace body.

Yiphee Electric Furnace Co.,Ltd specializes in producing induction furnace.Tel(WhatsApp):+86-13450756789, yiphee@yiphee.cn
